Frame | ALLOY 6061 HYDROFORMED |
 |
Fork | ALLOY DISC 381 |
 |
Rear Derailleur | SHIMANO TX35 21s |
 |
Derailleur | SHIMANO TZ30 |
 |
Shifters | SHIMANO EF41 |
 |
Crankset | MEGAMO 920 42-32-22 T |
 |
Cassette | SHIMANO TZ21 7s 14-28 T |
 |
Tires | 26” x 1,95“ |
 |
Wheels | MEGAMO DOBLE WALL ALLOY DISC |
* Megamo reserves the right to change any component, if necessary by replacing it with an equivalent one, without prior notice. |
| XS | S | M | |
|---|---|---|---|
| SIZE | 13" | 15" | 17" |
| T/T | 530 | 550 | 575 |
| C/S | 425 | 425 | 425 |
| S/T | 330 | 381 | 431 |
| H/T | 100 | 110 | 120 |
| FRONT ANGLE | 70º | 70º | 70º |
| REAR ANGLE | 73º | 73º | 73º |
