Frame | Alloy 6061 Double Butted, Hydroformed Technology, Internal Cable Routing |
 |
Fork | Suntour XCT 30 HLO DS 29 Travel 100 |
 |
Headset | 1-1/8" Semi Integrated |
 |
Rear Derailleur | Shimano Altus M310 8s |
 |
Derailleur | Shimano Altus M315 |
 |
Shifters | Shimano Altus M315 2x8s |
 |
Crankset | Shimano 315 36/22 |
 |
Cassette | Shimano HG31 11-34 8s |
 |
Brakes | Shimano MT200 Hydraulic Disc |
 |
Tires | 29" x 2,1 MTB / 27,5" x 2,1 MTB |
 |
Hubs | Formula |
 |
Wheels | Megamo Doble Wall Disc |
 |
Handlebar | Megamo Fov Compact |
 |
Stem | Megamo Fov Compact |
 |
Seatpost | Megamo 27,2mm |
 |
Seat | Megamo |
* Megamo reserves the right to change any component, if necessary by replacing it with an equivalent one, without prior notice. |
| S | M | L | XL | |
|---|---|---|---|---|
| SIZE | 15" | 17" | 19" | 21" |
| T/T | 575 | 600 | 625 | 650 |
| C/S | 435 | 435 | 435 | 435 |
| S/T | 390 | 440 | 480 | 530 |
| H/T | 90 | 100 | 115 | 130 |
| REACH | 400 | 420 | 440 | 462 |
| STACK | 600 | 608 | 622 | 636 |
| FRONT ANGLE | 69,5º | 69,5º | 69,5º | 69,5º |
| REAR ANGLE | 73,5º | 73,5º | 73,5º | 73,5º |
