Frame | Full Integratted Battery, Alloy Triple Butted, 12x148 Boost, Horst Link 4, Wheel travel: 160 mm, Tire clearance 29 x 2.6 |
 |
Fork | Rock Shox 35 Silver R 29" Boost 15x110mm 160mm E-MTB Tapered Steerer |
 |
Shock | Rock Shox Deluxe Select R 205x65 Debonair Tune Trunnion |
 |
Headset | FSA Orbit 1,5 E ZS 1-1/8” 1,5” |
 |
Motor | Shimano EP801 / 85 Nm |
 |
Battery | Integrated LI-ION Battery, 762 Wh |
 |
Display | Shimano Steps SC-EN600 |
 |
Rear Derailleur | Sram SX Eagle 12s |
 |
Shifters | Sram SX Eagle 12s |
 |
Crankset | Shimano 36t |
 |
Cassette | Sram SX Eagle 12s |
 |
Brakes | Shimano MT420 hydraulic disc 4-Piston, 203mm |
 |
Tires | Front: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO Protection / Pirelli Scorpion Eduro S HardWALL |
 |
Wheels | 29 Asymmetric 15x110 12x148 Boost Wide:30mm Tubeless Ready |
 |
Handlebar | Alloy Butted 31,8x780 mm, Rise: 12 mm, Back Sweep: 6º |
 |
Stem | 3D Forged Alloy, Ext.: 60-70-90 mm, Rise: ±7º |
 |
Seatpost | Megamo Ø 30.9mm telescopic seat post, remote adjustment |
 |
Seat | Selle Italia Model X |
* Megamo reserves the right to change any component, if necessary by replacing it with an equivalent one, without prior notice. |
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
|
|
|
|
|
|
|
|
