Frame | Full Integratted Battery, Alloy Triple Butted, 12x148 Boost, Horst Link 4, Wheel travel: 160 mm, Tire clearance 29 x 2.6 |
 |
Fork | Fox 38 Factory e-bike+, Kashima 29, 160mm, grip 2, 15QRx110, 44mm rake |
 |
Shock | Fox FLOAT X, Factory Series, Kashima 2pos-adj, Trunnion, Evol LV, 205x65 |
 |
Headset | FSA Orbit 1,5 E ZS 1-1/8” 1,5” |
 |
Motor | Shimano EP801 / 85 Nm |
 |
Battery | Integrated LI-ION Battery, 762 Wh |
 |
Display | Shimano Steps SC-EN600 |
 |
Rear Derailleur | Shimano XT 12s |
 |
Shifters | Shimano Deore 12s |
 |
Crankset | Shimano 36t |
 |
Cassette | Shimano Deore 12s 10-51t |
 |
Brakes | Shimano XT M8020 Hydraulic disc 4-Piston, 203mm |
 |
Tires | Front: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO Protection / Pirelli Scorpion Eduro S HardWALL |
 |
Wheels | 29 Asymmetric 15x110 12x148 Boost Wide:30mm Tubeless Ready |
 |
Handlebar | Alloy Butted 31,8x780 mm, Rise: 12 mm, Back Sweep: 6º |
 |
Stem | 3D Forged Alloy, Ext.: 60-70-90 mm, Rise: ±7º |
 |
Seatpost | FOX Transfer, Factory series (Kashima), Ø 30.9mm, Internal Routing, Remote |
 |
Seat | Selle Italia Model X Superflow |
* Megamo reserves the right to change any component, if necessary by replacing it with an equivalent one, without prior notice. |
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
||||
|
|
|
|
|
|
|
|
|
|
